| 1. |
86637269
|
[1] |
DRIVEN SPROCKET,RC80, 22T
|
NH
22T
|
| 4. |
136443
|
[1] |
WASHER,10.32mm ID x 57.15mm OD x 4.8mm Thk
|
NH
|
| 5. |
NS
|
[2] |
NOT SERVICED
|
BAS
SPROCKET 13T, Plastic, Production Only {87050058}
|
| 5. |
66614
|
[2] |
SPROCKET,RC80, 13T
|
NH
13T, Steel, Service Only Superseded by part number: 84401598
|
| 6. |
87030996
|
[2] |
IDLER
|
NH
Plastic
|
| 7. |
183356
|
[1] |
EYEBOLT,3/8" - 16 x 10" L
|
NH
G2, 3/8"-16 x 10-1/8"
|
| 8. |
86512547
|
[1] |
SPRING,Extension, 1.94" OD x 13 - 1/8" L
|
NH
Extension
|
| 9. |
86582659
|
[1] |
ARM
|
NH
Superseded by part number: 604085, 87655907
|
| 10. |
9804060
|
[1] |
CHAIN,80, 158 Links x 25.4mm = 4013.2mm
|
NH
RC80, 1"-pitch, 158 Pitches, Includes: Ref. 16
|
| 11. |
84019797
|
[1] |
SLEEVE,25mm ID x 28mm OD x 25mm L
|
NH
Superseded by part number: 604085
|
| 15. |
87483
|
[1] |
KEY,0.31" x 1.5" L
|
NH
|
| 16. |
9620569
|
[1] |
CONNECTING LINK,RC80, 1 Link x 25.4mm = 25.4mm L
|
NH
RC 80K Superseded by part number: 241-1418
|
| 17. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 18. |
43158
|
[1] |
BOLT,Hex, M12 x 80mm, Cl 8.8
|
NH
|
| 19. |
9804272
|
[1] |
BOLT,Hex, M16 x 50mm, Cl 8.8, Full Thd
|
NH
|
| 20. |
66553
|
[2] |
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
|
NH
|
| 21. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 23. |
80299
|
[4] |
WASHER,0.69" ID x 1.75" OD x 0.13" Thk
|
NH
|
| 24. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 25. |
80700
|
[2] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 27. |
26402
|
[1] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
(.060" Thk, 1-1/2" OD)
|
| 28. |
86509499
|
[2] |
JAM NUT,3/8"-16, G2
|
ZED
|
| 29. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 30. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 31. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 32. |
86542824
|
[2] |
SET SCREW,Sq Hd, 3/8" - 16 x 1-1/2"
|
NH
|
