神钢零件查询(F4GE9684G J601) - ENGINE - 504375341 - 84250441 (7/13-) (10.254.AM) - AIR INTAKE, MANIFOLD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2856513 | [1] | COVER | TOR |
| 2. | 4899039 | [10] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TORM8 x 1.25 x 25 |
| 3. | 4899921 | [1] | GASKET,1.2mm Thk | TOR |
| 4. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 4. | 2854866 | [2] | HEX SOCKET PLUG,3/4"-14 NPTF | TOR Superseded by part number: 4893036 |
| 5. | 4895424 | [1] | INLET MANIFOLD | TOR |
| 6. | 4895294 | [4] | BOLT,Flng, M8 x 1.25 x 80mm, Cl 10.9 | TORM8 x 1.25 x 80 |
| 6. | 2852212 | [4] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm | TORM8 x 1.25 x 25 |
