纽荷兰零件查询(DC180LGP) - CRAWLER DOZER (2/01-) (0.510[01]) - FUEL TANK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
162 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76071221 | [1] | FUEL TANK | LEC |
| 2. | 76041512 | [1] | HOSE,11.00 mm ID x 5000.00 mm | LEC Superseded by part number: 19056787 |
| 3. | 79105768 | [1] | FLEXIBLE HOSE,7.50 mm ID x 3100.00 mm | LEC Superseded by part number: 19056687 |
| 4. | 585834 | [2] | DRAINCOCK/TAP SUPPLY | LEC |
| 5. | 76071222 | [1] | FLANGE | LEC |
| 6. | 73100021 | [1] | GASKET,3.17mm Thk | LEC |
| 7. | 79104494 | [1] | CAP | LEC- ASSY |
| 8. | 79110132 | [1] | ELEMENT | LEC Superseded by part number: 79104494 |
| 9. | 4971843 | [1] | CIRCLIP | LEC |
| 10. | 79107317 | [1] | FILTER STRAINER | LECOIL INTAKE |
| 11. | 11112231 | [6] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 12. | 70928460 | [6] | WASHER | LEC |
| 13. | 79013422 | [2] | CABLE TIE,145mm L | LEC |
| 14. | 70933986 | [1] | ELBOW | LEC |
| 15. | 79084753 | [2] | HOSE CLIP,M10-18 | LEC |
| 16. | 79083842 | [2] | HOSE CLAMP,M16-27 | LEC20X30 Superseded by part number: 18088392 |
| 17. | 76046616 | [1] | SHIM | LEC |
| 18. | 11116031 | [6] | BOLT,Hex, M14 x 45, 10.9, Full Thd | LEC Superseded by part number: 87015765 |
| 19. | 79005238 | [6] | WASHER,14.8mm ID x 32mm OD x 7mm Thk | LEC14X32 |
| 20. | 76031267 | [1] | FUEL HOSE,11.00 mm ID x 450.00 mm | LEC Superseded by part number: 19056787 |
| 21. | 10448790 | [2] | CLAMP,30mm, Coat, 9mm Bolt Hole, P Type | LEC30 |
| 22. | 4982514 | [4] | CABLE TIE | LEC370 Superseded by part number: 87615202 |
