| 1. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 2. |
87027869
|
[1] |
ROLLER
|
PA
Drive Superseded by part number: 84496217
|
| 2. |
86635441
|
[1] |
ROLL
|
PA
Drive
|
| 3. |
87660299
|
[1] |
FEED ROLLER
|
NH
Floor, Includes: Round Rods
|
| 3. |
87398372
|
[1] |
ROLLER ASSY.,304.5mm OD x 1293mm L
|
PA
Floor, Includes: Square Rods
|
| 4. |
86628106
|
[2] |
SHIELD
|
NH
14mm Flange
|
| 4. |
87025815
|
[2] |
SHIELD
|
PA
18mm Flange
|
| 5. |
87374660
|
[1] |
FEED ROLLER
|
PA
Fixed Dimple, Includes: Square Rods Superseded by part number: 87602845, 87602845, 87660302
|
| 6. |
86611130
|
[1] |
SHAFT
|
NH
|
| 6. |
87056540
|
[1] |
SHAFT
|
PA
|
| 7. |
86636760
|
[2] |
RING
|
NH
|
| 8. |
86590752
|
[1] |
BEARING ASSY
|
NH
Superseded by part number: 87660333
|
| 9. |
86590753
|
[2] |
BEARING ASSY
|
NH
|
| 9. |
87027838
|
[2] |
BEARING ASSY
|
PA
40mm ID, Round
|
| 10. |
87056511
|
[1] |
SPROCKET
|
PA
28T, RC60
|
| 11. |
86837676
|
[4] |
FLANGED BEARING
|
PA
Superseded by part number: 86979948
|
| 12. |
286909
|
[2] |
BALL BEARING,38.11mm Hex x 84.99mm OD x 30mm W
|
NH
1-1/2" Hex Bore Superseded by part number: 47577178
|
| 13. |
87016738
|
[1] |
FRAME ASSY
|
PA
Main, North America, Includes: Decals
|
| 13. |
87016740
|
[1] |
FRAME ASSY
|
PA
Main, Europe & R.O.W., Includes: Decals Superseded by part number: 87016739
|
| 14. |
86622263
|
[2] |
HUB
|
NH
Superseded by part number: 87660304
|
| 15. |
86619043
|
[5] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
Plated
|
| 16. |
614-10020
|
[4] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 17. |
274247
|
[4] |
BOLT,Hex Flg, M10 x 16mm, Stainless
|
NH
|
| 18. |
614-12035
|
[26] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 19. |
614-16040
|
[4] |
BOLT,Hex, M16 x 2 x 40mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86509867
|
| 20. |
814-12050
|
[8] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 9706702
|
| 21. |
614-12040
|
[2] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 22. |
58821
|
[1] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
.060" Thk
|
| 23. |
86610638
|
[2] |
BEARING ASSY,45mm ID
|
NH
|
| 24. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 25. |
140046
|
[28] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 26. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 27. |
87056525
|
[2] |
WASHER
|
PA
|
| 28. |
87039466
|
[2] |
STRIPPER
|
PA
|
| 29. |
829-2412
|
[4] |
FLANGE NUT,M12 x 1.75, Flg, Cl 10
|
CAS
Superseded by part number: 86512497
|
| 30. |
84024216
|
[1] |
LOCK PIN,5mm OD x 50mm L, Slotted
|
PLO
|
| 31. |
219-417
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 571382
|
| 32. |
412689
|
[1] |
LOCK PIN,8mm OD x 50mm L, Slotted
|
NH
|
| 33. |
432-1232
|
[1] |
COTTER PIN,3/16" OD x 2" L
|
CAS
Superseded by part number: 87400
|
| 35. |
86976003
|
[1] |
SPACER
|
PA
, Serial Range: -35 Superseded by part number: 87660303
|
| 36. |
87037410
|
[4] |
HINGE
|
PA
Lower, Square-Shaped
|
| 37. |
308761
|
[8] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 38. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 39. |
825-2408
|
[8] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 40. |
86631518
|
[2] |
DANGER DECAL
|
NH
English
|
| 40. |
86632801
|
[2] |
DECAL
|
NH
DANGER, French
|
| 41. |
86636753
|
[1] |
PIN
|
NH
Tailgate Latch Pivot
|
| 48. |
87384472
|
[2] |
COLLAR
|
PA
Superseded by part number: 563733
|
| 49. |
86602047
|
[2] |
PIVOT PLATE
|
NH
Superseded by part number: 87660305
|
| 50. |
86602143
|
[2] |
WEAR PLATE
|
NH
|
