卡特零件查询（725C） 385-7680: ENGINE AR-COMPLETE
广数供应链运营团队, 14 02月, 2025，浏览：
149 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 439-5264Y | [1] | ALTERNATOR GP-CHARGING | |
| | | | S/N WYE1-UP |
| | 344-5154Y | [1] | BASE GP-OIL FILTER(REMOTE MOUNTED) | |
| | 352-9294Y | [1] | BELT GP-SERPENTINE | |
| | 327-3983Y | [1] | COMPRESSOR GP-REFRIGERANT | |
| | 394-8802Y | [1] | CONTROL & MTG GP-ENGINE ELEK | |
| | 188-3826Y | [1] | COOLER GP-ENGINE OIL | |
| | 325-8452Y | [1] | COVER GP-ENGINE | |
| | 127-5728Y | [1] | COVER GP-FLYWHEEL HOUSING | |
| | 269-5311Y | [1] | COVER GP-FRONT HOUSING(ENGINE OIL FILL) | |
| | 269-5325Y | [1] | COVER GP-FRONT HOUSING(OPTIONAL EQUIPMENT) | |
| | 338-2640Y | [1] | COVER GP-FRONT HOUSING | |
| | 416-5435Y | [1] | COVER & MTG GP-CYLINDER BLOCK | |
| | | | S/N WYE1-UP |
| | 349-1527Y | [1] | COVER GP-VALVE MECHANISM | |
| | 211-8041Y | [1] | DAMPER GP | |
| | 371-7971Y | [1] | ELBOW GP-AIR INLET | |
| | 278-0244Y | [1] | ELBOW GP-WATER | |
| | 435-4840Y | [1] | ENGINE AR | |
| | 218-0859Y | [1] | FASTENER GP-DAMPER & PULLEY | |
| | 346-5148Y | [1] | FASTENER GP-FUEL INJ PUMP | |
| | 348-1099Y | [1] | FASTENER GP-WATER PUMP | |
| | 383-0704Y | [1] | FILTER GP-FUEL | |
| | 251-2068Y | [1] | GAUGE GP-OIL LEVEL (DIPSTICK)(ENGINE) | |
| | 344-2902Y | [1] | HOUSING GP-FLYWHEEL | |
| | 299-8022Y | [1] | HOUSING GP-FRONT | |
| | 376-2385Y | [1] | LIFTING GP-ENGINE | |
| | 286-9679Y | [1] | LINES GP-ENGINE OIL | |
| | 442-6735Y | [1] | LINES GP-FUEL | |
| | | | S/N WYE1-UP |
| | 331-2758Y | [1] | LINES GP-FUEL | |
| | 385-4385Y | [1] | LINES GP-TURBOCHARGER OIL | |
| | 391-4948Y | [1] | MANIFOLD GP-EXHAUST | |
| | 344-8267Y | [1] | MANIFOLD GP-INLET | |
| | 444-5474Y | [1] | MANIFOLD GP-WATER | |
| | | | S/N WYE1-UP |
| | 344-0365Y | [1] | MOUNTING GP-ALTERNATOR & COMPR | |
| | 367-7314Y | [1] | MOUNTING GP-CONNECTOR(ENGINE) | |
| | | | S/N WYE1-UP |
| | 348-8185Y | [1] | PAN GP-OIL | |
| | 275-4260Y | [1] | PLUG GP-CYLINDER BLOCK(JACKET WATER HEATER) | |
| | 275-8699Y | [1] | PLUG GP-CYLINDER BLOCK(AUXILIARY COOLER) | |
| | 346-4997Y | [1] | PLUG GP-CYLINDER HEAD | |
| | | | -OR- |
| | 495-5748Y | [1] | PLUG GP-CYLINDER HEAD | |
| | 292-9786Y | [1] | PLUG GP-ENGINE(COMPRESSION BRAKE) | |
| | 347-2324Y | [1] | PLUG GP-WATER LINES | |
| | 342-7219Y | [1] | PULLEY GP-CRANKSHAFT | |
| | 326-3561Y | [1] | REGULATOR GP-TEMPERATURE | |
| | 295-2351Y | [1] | SEAL GP-CRANKSHAFT | |
| | 349-4782Y | [1] | SPACER GP-AIR INLET | |
| | 180-2435Y | [1] | STARTING MOTOR GP-ELECTRIC | |
| | 438-7504Y | [1] | SUPPORT GP-ENGINE | |
| | | | S/N WYE1-UP |
| | 397-8596Y | [1] | TURBOCHARGER GP | |
| | 439-3951Y | [1] | WIRING GP-ELECTRONIC CONTROL | |
| | | | S/N WYE1-UP |
| | | | |
| | | | PLEASE USE THE GASKET KIT LINK IN SIS OR CONTACT YOUR LOCAL DEALER FOR THE LATEST GASKET KIT INFORMATION |
| | Y | | SEPARATE ILLUSTRATION |
