神钢零件查询(F4GE9684R J603) - ENGINE - 504369116 - 84190728 (1/08-12/12) (10.103.01) - CRANKSHAFT (2852304) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
891 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852305 | [1] | CRANKSHAFT | TORASSY Superseded by part number: 4899046, 504203872 |
| 2. | 4893386 | [1] | GEAR,36 T | TOR |
| 3. | 4899046 | [1] | DOWEL,M6 x 9 L | TOR |
| 4. | 2995787 | [6] | SET OF STD MAIN BRGS | TOR |
| 4. | 2995788 | [6] | SET OF MAIN BRGS-.25 | TOR Superseded by part number: |
| 4. | 2995789 | [6] | SET OF MAIN BRGS - | TOR |
| 5. | 2995784 | [1] | SET OF THRUST WASHER | TOR |
| 5. | 2995785 | [1] | SET OF MAIN BRGS-.25 | TOR(+0.254) (+0.250) |
| 5. | 2995786 | [1] | SET OF THRUST WASHER | TOR(+0.508) (+0.500) |
