神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.101.AB[02]) - VALVE COVER, FROM SERIAL NUMBER 1462088 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
471 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 504262827 | [1] | CAP | TORASSY, Incl 3, 4 |
| 3. | 98412146 | [1] | GASKET | TOR Superseded by part number: 2852774 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 2 |
| 5. | 504075125 | [6] | FLANGE NUT | TOR Superseded by part number: 4893936 |
| 6. | 504070037 | [1] | CYLINDER HEAD GASKET,10.5mm Thk | CYLINDER HEAD GASKET,10.5mm Thk |
| 7. | 504070041 | [6] | GASKET | TOR Superseded by part number: 4899239 |
| 8. | 504308965 | [1] | COVER | CUR |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONCover, Incl in 1 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Incl in 10 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONO-ring, Incl in 10 |
| 13. | 504088235 | [4] | SCREW | CUR |
| 14. | 5801545974 | [2] | | |
| 15. | 5802112500 | [1] | FILTER | FILTER |
| 16. | 5802276802 | [1] | VALVE | VALVE |
