神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.210.AF) - FUEL SUPPLY LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
112 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 4894095 | [2] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONELEC CONNECTOR PIPE, Incl in 1 |
| 5. | 4894095 | [6] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONELEC CONNECTOR PIPE, Incl in 7 |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONO-RING, Incl in 13 |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 13 |
