神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.218.AI[02]) - INJECTOR FUEL LINES Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
422 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Fuel supply, Incl in 3 |
| 3. | 2857022 | [1] | PIPE | TORAssy, Fuel supply, Incl 2, 9 - 14 |
| 4. | 2857017 | [2] | PIPE | TORAssy, Fuel supply, Incl 7 - 8 Superseded by part number: |
| 5. | 2857020 | [2] | PIPE | TORAssy, Fuel supply, Incl 6 - 7 Superseded by part number: |
| 7. | 2854548 | [2] | SILENTBLOC | TORIsolator vibration |
| 8. | NSS | [2] | NOT SOLD SEPARAT | CONPipe, Fuel supply, Incl in 4 |
| 9. | 2854557 | [2] | CLAMP BRACKET | TORPipe anchoring |
| 10. | 2854556 | [2] | CLAMP BRACKET | TORPipe anchoring |
| 10. | 2854558 | [2] | RUBBER SEAL | TORPipe anchoring |
| 12. | 2854555 | [1] | CLAMP BRACKET | TORPipe anchoring |
| 13. | 2852434 | [1] | SPACER | TOR8.5mm ID x 18mm OD x 5mm L Superseded by part number: 13605711 |
| 14. | 2854559 | [2] | SCREW | TOR Superseded by part number: |
| 15. | 4896884 | [1] | BOLT,Flng, M8 x 1.25 x 16mm, Cl 10.9 | TOR |
| 14. | 4899020 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
