神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.250.AE) - TURBOCHARGER LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
903 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852101 | [2] | FLANGE BOLT,Hex, M6 x 16mm | TORM6 x 1 x 16mm Superseded by part number: 18137825 |
| 2. | 4899467 | [1] | GASKET | TOROil drain |
| 3. | 4899519 | [1] | CLAMP,M16, M6 Bolt | TOR |
| 4. | 17281681 | [2] | O-RING,13.90mm ID x 2.60mm | LEC Superseded by part number: 14457181 |
| 6. | 4895089 | [1] | PLUG,0.886" L | TORExpansion |
| 7. | 2852100 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 16mm | TOR Superseded by part number: 16586225 |
| 8. | NS | [1] | NOT SERVICED | BASBracket |
