现代零件查询R110-7A MAIN CONTROL VALVE(2/4, #0118-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
249 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 16. |
XKCG-00505
|
[2] |
MAIN RELIEF V/V
|
|
| 17. |
XKCG-00506
|
[4] |
OVERLOAD RELIEF V/V(STD)
|
|
| 28. |
XKCG-00447
|
[6] |
PLUG
|
|
| 29. |
XKCG-00263
|
[5] |
PLUG
|
|
| 31. |
XKCG-00052
|
[6] |
PLUG
|
|
| 32. |
XKCG-00514
|
[1] |
PLUG(PF 3/4)
|
|
| 33. |
XKCG-00472
|
[1] |
PLUG
|
|
| 35. |
XKCG-00062
|
[1] |
PLUG
|
|
| 38. |
XKCG-00517
|
[1] |
PLUG(BUCKET M18X1.5)
|
|
| 39. |
XKCG-00518
|
[1] |
PLUG(BUCKET PARALLEL)
|
|
| 41. |
XKCG-00045
|
[1] |
ORIFICE-PLUG
|
|
| 42. |
XKCG-00236
|
[3] |
NPT-1/16
|
|
| 43. |
XKCG-00520
|
[5] |
POPPET-LOAD CHECK D20
|
|
| 44. |
XKCG-00521
|
[5] |
POPPET-LOAD CHECK D16
|
|
| 45. |
XKCG-00157
|
[1] |
POPPET CHECK VALVE
|
|
| 58. |
P8 N552-90
|
[1] |
O-RING 1B P8
|
|
| 59. |
P10 N552-90
|
[3] |
Deleted...
|
|
| 61. |
P11 N552-90
|
[2] |
O-RING 1B P11
|
|
| 62. |
P14 N552-90
|
[7] |
Deleted...
|
|
| 63. |
P15 N552-90
|
[7] |
O-RING 1B P15
|
|
| 66. |
P22 N552-90
|
[14] |
Deleted...
|
|
| 67. |
P24 N552-90
|
[1] |
O-RING 1B P24
|
|
| 71. |
2-015 N552-90
|
[1] |
Deleted...
|
|
| 72. |
108480
|
[5] |
Deleted...
|
|
| 74. |
XKCG-00532
|
[1] |
BACKUP-RING
|
|
| 75. |
XKCG-00533
|
[2] |
BACKUP-RING; P10
|
|
| 76. |
XKCG-00534
|
[2] |
BACKUP-RING; P11
|
|
| 79. |
XKCG-00535
|
[5] |
SPRING-LOAD CHECK D20
|
|
| 80. |
XKCG-00536
|
[5] |
SPRING-LOAD CHECK D16
|
|
| 81. |
XKCG-00156
|
[1] |
SPRING-CHECK
|
|
