现代零件查询R110-7A SWING REDUCTION GEAR (2/2, TYPE 2)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
320 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
38N4-10150
|
[1] |
SWING MOTOR ASSY
|
|
| -1. |
38N4-11100
|
[1] |
SWING MOTOR
|
|
| -2. |
39N4-12100
|
[1] |
SWING REDUCTION GEAR
|
|
| 1. |
39Q4-12110
|
[1] |
GEAR-RING
|
|
| 2. |
39Q4-12120
|
[1] |
DRIVE SHAFT
|
|
| 3. |
39Q6-12140
|
[1] |
BEARING-TAPER,SUB
|
|
| 4. |
39Q4-12130
|
[1] |
BEARING-TAPER/SUB
|
|
| 5. |
39Q4-12140
|
[1] |
NUT RING
|
|
| 6. |
39Q4-12150
|
[1] |
LOCK PLATE(NUT RING)
|
|
| 7. |
S017-080126
|
[4] |
BOLT-HEX
|
|
| 8. |
39N4-12160
|
[1] |
CASING
|
|
| 9. |
S109-141306
|
[10] |
BOLT-SOCKET
|
|
| K10. |
39Q4-12180
|
[1] |
CARRIER NO.2
|
|
| K11. |
39Q4-12190
|
[3] |
GEAR-PLANETARY NO.2
|
|
| K12. |
39Q6-42280
|
[3] |
BEARING-NEEDLE 1
|
|
| K13. |
39Q4-12200
|
[6] |
WASHER-THRUST NO.2
|
|
| K14. |
39Q4-12210
|
[3] |
PIN-CARRIER NO.2
|
|
| KS15. |
S472-600364
|
[6] |
PIN-SPRING
|
|
| K16. |
39Q4-12220
|
[1] |
GEAR-SUN NO.2
|
|
| S17. |
39Q4-12240
|
[1] |
CARRIER NO.1
|
|
| S18. |
39Q4-12250
|
[3] |
GEAR-PLANETARY NO.1
|
|
| S19. |
39Q4-12260
|
[3] |
BEARING-NEEDLE NO.1
|
|
| S20. |
39Q4-12270
|
[3] |
WASHER-THRUST NO.1
|
|
| S21. |
39Q4-12280
|
[3] |
PIN-CARRIER NO.1
|
|
| S22. |
39Q4-12290
|
[1] |
GEAR-SUN NO.1
|
|
| S23. |
S751-032004
|
[3] |
RING-SNAP
|
|
| KS24. |
39Q4-12300
|
[2] |
PLATE-THRUST
|
|
| 25. |
39Q4-12310
|
[1] |
SLEEVE
|
|
| 26. |
S632-095001
|
[1] |
O-RING
|
|
| 27. |
39Q4-12320
|
[1] |
OIL SEAL
|
|
| 28. |
39N4-12330
|
[1] |
NAME PLATE
|
|
| 29. |
39Q6-41800
|
[2] |
RIVET
|
|
| 30. |
P220-430204
|
[1] |
PLUG-HEX
|
|
| 31. |
39Q4-12340
|
[1] |
PIN-PARALLEL
|
|
| S32. |
39Q4-12350
|
[3] |
WASHER-THRUST NO.1
|
|
| K. |
39Q4-12170
|
[1] |
CARRIER NO.2 KIT
|
|
| S. |
39Q4-12230
|
[1] |
CARRIER NO.1 KIT
|
|
