神钢零件查询(F4HFE413A E001) - ENGINE 5801451663 - 84371229 (1/13-) (10.247.0101) - INJECTION PUMP - COMPONENTS (84385110) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
925 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 42541851 | [1] | SOLENOID | IMOASSY |
| 2. | 42541850 | [1] | O-RING | TOR |
| 3. | 42541849 | [1] | O-RING | TOR |
| 4. | 42547619 | [1] | FUEL PUMP | TOR Superseded by part number: 42559145 |
| 5. | 42550488 | [1] | O-RING | TOR |
| 6. | 42548060 | [1] | O-RING | TOR |
| 7. | 42550487 | [4] | SCREW | TOR Superseded by part number: 42556891 |
| 8. | 42550932 | [3] | SCREW | TOR Superseded by part number: 42556819 |
| 9. | 42550486 | [1] | VALVE | TOR |
