纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.439[03]) - REAR EQUIPMENT PIPING - VERSION (01) - OPTIONAL CODE 76069530 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
692 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79094128 | [2] | HYD CONNECTOR | LEC3/4G-1"3/16- ASSY Superseded by part number: 154221912 |
| 2. | 76007732 | [4] | HALF-FLANGE | LECSAE 3/4 |
| 3. | 76046669 | [2] | FLEXIBLE HOSE | LEC- RIPPER CONTROL |
| 4. | 14463281 | [2] | O-RING,0.984" ID x 0.139" Width | TTF |
| 5. | 79096188 | [2] | FLANGE | LEC |
| 6. | 14420431 | [8] | HEX SOC SCREW,M10 x 1.5 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 14420434 |
| 7. | 11701721 | [8] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 8. | 70923843 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | LEC1,78X18,77 Superseded by part number: 66297 |
