神钢零件查询(F4HFE413A E002) - ENGINE 5801451664 - 84371230 (1/13-) (10.304.01[01]) - OIL LEVEL CHECK (2855811 - 2853115) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
621 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY |
| 4A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 5. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 6. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 7. | 2857051 | [1] | PLASTIC PLUG,25mm ID, 70mm L | TOR |
| 8. | 2853118 | [1] | BOLT,Hex, M6 x 1 x 18mm | TOR Superseded by part number: 16597225 |
| 10. | 2852485 | [1] | BRACKET | TOR Superseded by part number: 17316592 |
| 11. | 4895406 | [2] | EXPANSION PLUG,9.8mm OD | TOR |
