纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[14A]) - ROPS CAB - ELECTRICAL SYSTEM - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1003 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 76067655 | [1] | ELECTRIC CABLE | LECASSY |
| 3. | 76067641 | [1] | KNOB | LEC |
| 4. | 13307677 | [2] | SCREW,M3 x 10mm | LEC |
| 5. | 13307977 | [1] | SCREW,M3 x 16mm | LEC |
| 6. | 76067643 | [1] | RING | LEC |
| 7. | 15902601 | [3] | SCREW,Pozidriv Pan Hd, 9.50mm L | LEC Superseded by part number: 15902604 |
| 8. | 76067642 | [1] | HOLDER | LEC |
| 9. | 76067710 | [1] | SWITCH | LEC |
| 10. | 76067711 | [3] | SWITCH | LEC |
| 11. | 76067712 | [2] | SWITCH | LEC |
| 12. | 76067656 | [1] | ELEC CONNECTOR | LEC |
| 13. | 76067657 | [1] | ELEC CONNECTOR | LEC |
| 14. | 76067663 | [2] | COVER PLATE | LEC |
| 15. | 76067648 | [4] | PLATE | LEC |
| 16. | 76067664 | [6] | CABLE TIE | LEC |
| 17. | 76067644 | [1] | BEZEL | LEC |
