纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.665[07]) - AIR CONDITIONING - CONDENSER - OPTIONAL CODE 76066319 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
490 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76053671 | [1] | CONDENSER | NH, Serial Range: -C3933 Superseded by part number: 76052520 |
| 2. | 76053672 | [3] | SPARE PART | TOR, Serial Range: -C3933 Superseded by part number: 76027755 |
| 3. | 14496321 | [12] | WASHER | LEC5,3, Serial Range: -C3933 |
| 4. | 76035117 | [3] | CLAMP | NH, Serial Range: -C3933 Superseded by part number: 79013422 |
| 5. | 14197890 | [12] | NUT | LEC5X1,8, Serial Range: -C3933 Superseded by part number: 14197894 |
| 6. | 10978021 | [12] | BOLT,Hex, M5 x 20mm, Cl 8.8, Full Thd | BHB, Serial Range: -C3933 Superseded by part number: |
