纽荷兰零件查询(DC180PS) - CRAWLER DOZER (11/00-) (5.645[01]) - ROPS SUPPORT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
507 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76069315 | [1] | SUPPORT | LEC |
| 2. | 76026364 | [8] | STEP BOLT,Hex, M24 x 2 x 360mm, Cl 10.9 | LEC |
| 3. | 76002739 | [8] | WASHER | LEC Superseded by part number: 79005245 |
| 4. | 76046630 | [1] | FLAP | LEC- LEFT |
| 5. | 76046631 | [1] | FLAP | LEC- RIGHT |
| 6. | 76046632 | [1] | SHIELD | LEC- LEFT |
| 7. | 76046633 | [1] | SHIELD | LEC- RIGHT |
| 8. | 16043431 | [2] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 9. | 12645031 | [2] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 10. | 14420031 | [4] | HEX SOC SCREW,M10 x 20mm, Cl 10.9 | LEC |
| 11. | 12626231 | [32] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 12. | 76046634 | [1] | DOOR | LEC |
| 13. | 11106231 | [24] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 14. | 79106820 | [2] | SPRING | LEC |
| 15. | 10977531 | [4] | BOLT,Hex, M5 x 10mm, Cl 10.9, Full Thd | LEC |
| 16. | 10615379 | [4] | LOCK WASHER,Ext Tooth, M5 | LEC Superseded by part number: |
| 17. | 76069348 | [2] | BRACKET | LEC |
| 18. | 76054591 | [1] | SHIELD | LEC- LEFT |
| 19. | 76054592 | [1] | SHIELD | LEC- RIGHT |
