凯斯零件查询(RBX561) - CASE IH ROUND BALER (12/01-8/02) (041) - EXPELLER ROLLER KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
788 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86643786
|
[1] |
DIA KIT, HARVESTER
|
PA
Expeller Roller Superseded by part number: 87347750
|
| . . |
825-2408
|
[4] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 2. |
86636769
|
[1] |
SCRAPER BLADE
|
NH
|
| . . |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 3. |
9608117
|
[1] |
SHAFT
|
NH
Includes: Ref. 4 Superseded by part number: 87023401
|
| . . |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
17/32" ID x 2" OD x 3/16" Thk
|
| . . |
614-12030
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| . . |
65319
|
[2] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 4. |
838-5526
|
[2] |
LOCK PIN,M5 x 26, Slotted
|
CAS
Superseded by part number: 82848074, 130045
|
| 5. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 6. |
86637216
|
[1] |
ROLLER
|
NH
Expeller, Includes: Ref. 7 Superseded by part number: 47510516
|
| 7. |
8050825
|
[2] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 8. |
86637219
|
[2] |
SHIELD
|
NH
|
