现代零件查询R140LC-7 TOOL BOX MOUNTING(#1001-, TIER II)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
691 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TOOL BOX MOUNTING
|
|
| 2. |
71N8-42005
|
[1] |
PIPE WA
|
|
| 2. |
71N8-42005BG
|
[1] |
PIPE WA
|
|
| 3. |
71N8-46000
|
[1] |
MIRROR
|
|
| 3. |
71N8-48000
|
[1] |
MIRROR & STAY ASSY-RH
|
|
| 3. |
71N8-48001
|
[1] |
MIRROR & STAY ASSY-RH
|
|
| 3. |
71N8-48001BG
|
[1] |
MIRROR & STAY ASSY-RH
|
|
| 3-1. |
71N8-47100
|
[1] |
MIRROR
|
|
| 3-2. |
71N8-48100
|
[1] |
STAY ASSY-RH
|
|
| 3-2. |
71N8-48101
|
[1] |
STAY ASSY-RH
|
|
| 3-2. |
71N8-48101BG
|
[1] |
STAY ASSY-RH
|
|
| 4. |
71N8-45000
|
[1] |
STAY-MIRROR
|
|
| 4-1. |
S015-080406
|
[2] |
BOLT-HEX
|
|
| 4-2. |
S411-080006
|
[2] |
WASHER-SPRING
|
|
| 5. |
S390-015040
|
[4] |
SHIM-ROUND(0.5T)
|
|
| 6. |
S037-122556
|
[10] |
BOLT-W/WASHER
|
|
| 8. |
S037-122526
|
[4] |
BOLT-W/WASHER
|
|
| 9. |
71N4-44100
|
[1] |
COVER-F/TANK
|
|
| 9. |
71N4-44200
|
[1] |
COVER-F/TANK
|
|
| 10. |
74N4-47100
|
[1] |
FOOT BOARD WA(A)
|
|
| 11. |
S037-121556
|
[4] |
BOLT-W/WASHER
|
|
| 22. |
71N8-47101
|
[1] |
MIRROR
|
|
| 23. |
71N8-48102BG
|
[1] |
STAY ASSY-RH
|
|
