纽荷兰零件查询(DC180PS) - CRAWLER DOZER (11/00-) (1.277[02]) - FINAL DRIVE - COMPONENTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
595 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76040637 | [2] | DRIVEN GEAR | LEC |
| 2. | 76046799 | [2] | DRIVEN GEAR | LEC |
| 3. | 76040638 | [2] | DRIVING GEAR | LEC |
| 4. | 24940180 | [2] | ROLLER BEARING,90mm OD x 33mm | LEC40X90 Superseded by part number: 24941640 |
| 5. | 76040734 | [2] | ROLLER BEARING,70mm ID x 150mm OD x 35mm W | LEC60X150X35 |
| 6. | 24940310 | [2] | ROLLER BEARING,70mm ID x 150mm OD x 51mm W | LEC70X150 |
| 7. | 24940300 | [2] | ROLLER BEARING,55mm ID x 120mm OD x 43mm W | LEC55X120 |
| 8. | 76040661 | [2] | AXLE | LEC- WHEEL |
| 9. | 76040669 | [2] | BALL BEARING,130.03mm ID x 200.05mm OD x 100mm W | LEC |
| 10. | 76009262 | [2] | CYLINDRICAL ROLLER BEARING,95mm ID x 170mm OD x 43mm W | LEC |
| 11. | 76029105 | [2] | SEAL,197mm ID x 245mm OD x 41mm Thk | LEC |
| 12. | 76040670 | [2] | SPACER | LEC |
| 13. | 76040666 | [2] | SPACER | LEC |
| 14. | 76040665 | [2] | SPACER | LEC |
| 15. | 11078476 | [2] | SNAP RING,M170, Int | LEC |
