凯斯零件查询(RBX562) - CASE IH ROUND BALER (9/02-7/05) (08.57) - SHIELDS, BALE COMMAND™, TWINE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
791 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86637364
|
[1] |
SHEET
|
NH
Superseded by part number: 87661897
|
| 4. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Electric Twine Wrap
|
| 8. |
86610200
|
[8] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 10. |
86900410
|
[1] |
SHIELD
|
PA
|
| 11. |
86637363
|
[1] |
SHEET
|
NH
Superseded by part number: 87661899
|
| 17. |
844-6020
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 19. |
844-8020
|
[7] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 20. |
811-8020
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 22. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[15] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 26. |
825-2406
|
[1] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 27. |
825-2408
|
[7] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 37. |
87014359
|
[1] |
DOOR ASSY.
|
PA
Includes: Decals
|
| 38. |
86511841
|
[7] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
