现代零件查询R140LC-7 TRAVEL MOTOR(1/3, #0239-#2712, LCM-7)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
434 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31EL-40010
|
[1] |
TRAVEL MOTOR ASSY
|
|
| -1. |
XKAH-00481
|
[1] |
TRAVEL MOTOR UNIT
|
|
| -5. |
XKAH-00321
|
[1] |
C/BLOCK & PISTON KIT
|
|
| -51. |
XKAH-00068
|
[1] |
PISTON ASSY
|
|
| N105. |
XKAH-00069
|
[9] |
PISTON
|
|
| N106. |
XKAH-00070
|
[9] |
SHOE
|
|
| 104. |
XKAH-00071
|
[1] |
BLOCK-CYLINDER
|
|
| 107. |
XKAH-00072
|
[1] |
PLATE-RETAINER
|
|
| 108. |
XKAH-00073
|
[1] |
BALL-THRUST
|
|
| 110. |
XKAH-00074
|
[2] |
WASHER
|
|
| 111. |
XKAH-00318
|
[1] |
COLLAR
|
|
| 114. |
XKAH-00076
|
[1] |
SPRING
|
|
| 151. |
XKAH-00077
|
[5] |
ROLLER
|
|
| -6. |
XKAH-00078
|
[1] |
PISTON KIT-2 SPEED
|
|
| N161. |
XKAH-00079
|
[1] |
PISTON-2 SPEED
|
|
| N162. |
XKAH-00080
|
[1] |
SHOE-2 SPEED
|
|
| 102. |
XKAH-00081
|
[1] |
SHAFT-MAIN
|
|
| 103. |
XKAH-00467
|
[1] |
PLATE-SWASH
|
|
| 109. |
XKAH-00468
|
[1] |
PLATE-TIMING
|
|
| 112. |
XKAH-00084
|
[1] |
PISTON-PARKING
|
|
| 113. |
XKAH-00085
|
[12] |
SPRING
|
|
| 115. |
XKAH-00086
|
[2] |
PLATE-FRICTION
|
|
| 116. |
XKAH-00087
|
[2] |
PLATE-MATING
|
|
| K132. |
XKAH-00088
|
[1] |
SEAL-OIL
|
|
| K135. |
XKAH-00089
|
[1] |
O-RING
|
|
| K139. |
XKAH-00090
|
[1] |
O-RING
|
|
| 145. |
XKAH-00091
|
[1] |
RING-SNAP
|
|
| 149. |
XKAH-00092
|
[1] |
BEARING-BALL
|
|
| 150. |
XKAH-00093
|
[1] |
BEARING-BALL
|
|
| 167. |
XKAH-00095
|
[1] |
PIVOT
|
|
| 171. |
XKAH-00034
|
[2] |
PIN-PARALLEL
|
|
| 193. |
XKAH-00094
|
[1] |
SPRING
|
|
| -2. |
@
|
[1] |
REDUCTION GEAR
|
|
| K. |
XKAH-00111
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT INDIVIDUALLY SUPPLIED
|
|
