沃尔沃零件查询D4-180I-F; D4-225A-F; D4-225I-F; D4-260A-F; D4-260D-F; D4-260I-F; D4-300A-F; D4-300D-F; D4-300I-FSteering SystemPower Steering PumpEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
339 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
|
|
|
|
| 2. |
856768
|
[1] |
Bracket
|
|
| 3. |
21287109
|
[1] |
Hydraulic hose
|
|
| 3. |
21503249
|
[1] |
Hydraulic hose
|
For jackshaft
|
| 4. |
3863190
|
[1] |
Reservoir
|
|
| 5. |
21757268
|
[1] |
Cap
|
|
| 6. |
978166
|
[2] |
Hose clamp
|
|
| 7. |
996189
|
[1] |
Hose
|
|
| 8. |
3588105
|
[1] |
Coupling
|
|
| 9. |
3807238
|
[1] |
Tube
|
|
| 10. |
3863252
|
[1] |
Elbow
|
|
| 11. |
21757269
|
[1] |
Cap
|
|
| 12. |
21769163
|
[1] |
Gasket
|
|
| 13. |
3808486
|
[1] |
Hydraulic hose
|
|
| 14. |
941995
|
[1] |
Hose
|
L=2,5m
|
| 15. |
961664
|
[3] |
Hose clamp
|
|
| 15. |
961666
|
[2] |
Hose clamp
|
|
| 16. |
856768
|
[1] |
Bracket
|
|
