神钢零件查询(F4HFE413H A001) - ENGINE 504388926 - YM02P00013P1 (1/13-) (10.105.02) - CONNECTING ROD (84496915) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
209 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TORASSY |
| . . | 2831298R | [4] | REMAN-CONNECTING ROD | TORSK170-9 - Acera Mark 9 Tier 4, ASN YM08U2000 (1/12), |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 2856309 | [4] | CRANKSHAFT BEARING | BHB |
| 4. | 4892715 | [4] | BEARING LINER | TORBEARING, CON. ROD |
