纽荷兰零件查询(DC180PS) - CRAWLER DOZER (11/00-) (6.782[01A]) - TRADE MARK DECALS - N.A. VERSION (02) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
455 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76073328 | [1] | KIT | TORDECAL - Includes Items 2 thru 12 |
| 2. | 76069710 | [2] | MAKERS BADGE | TORDECAL, NEW HOLLAND |
| 3. | 76069712 | [1] | MAKERS BADGE | TORDECAL, NEW HOLLAND |
| 4. | 76069711 | [2] | TYPE PLATE | TORDECAL, DC180 Model |
| 5. | 76069768 | [1] | DEALERSHIP IDENTITY LOGO | TORLOGO |
| 6. | 76069739 | [2] | MAKERS BADGE | TORDECAL, NEW GENERATION |
| 7. | 76069713 | [1] | DECAL | TORRED STRIPE - LH |
| 8. | 76069732 | [1] | DECAL | TORRED STRIPE - RH |
| 9. | 76069734 | [1] | DECAL | TORRED STRIPE - LH |
| 10. | 76069735 | [1] | DECAL | TORRED STRIPE - RH |
| 11. | 76069779 | [1] | IDENTITY PLATE | LECPLATE, OPERATION INSTRUCTION |
| 12. | 76073319 | [2] | DECAL | TORPOWER STEERING |
| 13. | 76073320 | [1] | DECAL | TORLH |
| 14. | 76073321 | [1] | DECAL | TORRH |
| 15. | 76073338 | [2] | DECAL | TOR' LT' |
