纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (2.323[01A]) - HYDROSTATIC DRIVE COUPLER WITHOUT PTO DC70 - DC80 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 76593235 | [6] | BEARING ASSY | MACBEARING Superseded by part number: 20141040 |
| 5. | 76591430 | [3] | KEY | MAC Superseded by part number: 10619610 |
| 6. | 76591431 | [2] | SHAFT | MAC |
| 7. | 76591432 | [2] | GEAR | MAC |
| 12. | 76591433 | [1] | CASE | MAC |
| 13. | 76591434 | [1] | SHIM | MAC Superseded by part number: 76606889 |
| 14. | 76590938 | [1] | O-RING | MAC Superseded by part number: 70923601 |
| 15. | 76591436 | [1] | COVER | MAC |
| 21. | 76591437 | [2] | PLUG | MAC Superseded by part number: 10304911 |
| 22. | 76591438 | [2] | GASKET | MAC Superseded by part number: 98429280 |
| 25. | 76591439 | [1] | GEAR | MAC |
| 26. | 76591440 | [1] | SHAFT | MAC |
| 28. | 76591441 | [1] | PIN | MACGUIDE |
| 29. | 76591442 | [1] | COVER | MAC |
| 30. | 76591021 | [19] | LOCK WASHER | MACWASHER, LOCK |
| 31. | 76591444 | [19] | SCREW | MAC |
| 32. | 76591445 | [1] | GASKET | MAC |
| 41. | 76604201 | [1] | SPLINED COUPLING | MACCOUPLER WITHOUT PTO |
| 42. | 76606889 | [21] | SHIM | MAC |
| 43. | 47323066 | [1] | ROD | MAC |
| 44. | 47323067 | [1] | HYD CONNECTOR | MACFITTING |
| 45. | 47323068 | [1] | PLUG | MAC |
| 46. | 47323069 | [1] | RIGID TUBE | MACHOSE |
| 47. | 47323070 | [1] | HYD CONNECTOR | MACFITTING |
| 48. | 47323071 | [1] | HYD CONNECTOR | MACFITTING |
| 49. | 47323072 | [1] | CLAMP | MAC |
| 50. | 76590713 | [6] | WASHER | MAC Superseded by part number: 14496621 |
| 51. | 76590714 | [3] | SCREW | MAC Superseded by part number: 9515003 |
| 52. | 47323073 | [3] | NUT | MAC Superseded by part number: 190003888452 |
| 53. | 76593024 | [1] | CLAMP | MAC |
| 54. | 47323074 | [1] | BRACKET | MAC |
| 55. | 47323064 | [1] | BRACKET | MAC |
| 56. | 47323065 | [1] | RIGID TUBE | MACHOSE |
