凯斯零件查询(RBX562) - CASE IH ROUND BALER (9/02-7/05) (88.088.01) - DIA KIT, CNH 5FT FRONT TWINE BOX KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
703 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87681837
|
[1] |
DIA KIT, HARVESTER
|
NH
CNH 5 Foot Front Twine Box, Incl 2 - 16
|
| 2. |
87682073
|
[1] |
INSTRUCTION
|
NH
CNH Front Twine Box Kit
|
| 3. |
87681836
|
[1] |
TWINE BOX
|
NH
5 Foot Weld Assembly Dark Gray
|
| 4. |
86551339
|
[5] |
DIVIDER
|
NH
Black
|
| 5. |
632732
|
[1] |
LATCH
|
NH
Slide
|
| 6. |
87045140
|
[1] |
DOOR ASSY.
|
PA
Weld Dark Gray
|
| 7. |
86977986
|
[4] |
WASHER
|
NH
|
| 8. |
9804255
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 9. |
9804258
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 10. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 12. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 13. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 14. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 15. |
87016348
|
[1] |
5 Foot Front Twine Box Ship Group
|
|
| 16. |
86610200
|
[4] |
THREADED INSERT,M8 x 1.25
|
NH
|
