凯斯零件查询(RBX563) - CASE IH ROUND BALER (9/05-12/06) (03.20) - GEARBOX, MOUNTING, 1000 RPM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
692 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86626271
|
[1] |
DIPSTICK
|
NH
|
| 2. |
87025453
|
[1] |
GEARBOX
|
PA
Main Drive, 1000 RPM Superseded by part number: 87344585
|
| . . |
87344585R
|
[1] |
REMAN-PTO GEARBOX A.
|
PA
RBX563, Reman For New P/N's 87344585 & 87344585,
|
| . . |
87344585C
|
[1] |
CORE-PTO GEARBOX A.
|
PA
Return Number
|
| 3. |
86634418
|
[1] |
COUPLING
|
NH
Superseded by part number: 87661924
|
| 6. |
614-16040
|
[4] |
BOLT,Hex, M16 x 2 x 40mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86509867
|
| 9. |
86979179
|
[4] |
WASHER,16.67mm ID x 34.93mm OD x 6.35mm Thk
|
NH
1-3/8" OD
|
| 10. |
86637396
|
[2] |
WASHER,25.6mm ID x 35.3mm OD x 1mm Thk
|
NH
Special
|
| 11. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 12. |
86637370
|
[2] |
SEAL,40mm ID x 52mm OD x 7mm Thk
|
NH
Oil
|
| 13. |
300643
|
[2] |
SNAP RING,M38, Int
|
NH
Superseded by part number: 11059776
|
| 14. |
62161
|
[2] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
Self-Tapping
|
