卡特零件查询（725C） 394-8184: FENDER GP
广数供应链运营团队, 14 02月, 2025，浏览：
676 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 506-3235 | [1] | PLATE-FORMED | |
| 2. | 360-0594 | [4] | BRACKET | |
| 3. | 382-6596Y | [1] | PANEL GP-FENDER(FRONT, LH) | |
| 4. | 382-6597 | [1] | COVER GP-FENDER(FRONT, RH) | |
| | 257-7097D | | SEAL(1-M) | |
| | 360-1980 | [3] | CLIP | |
| 5. | 435-1702 | [1] | SPACER | |
| 6. | 238-0251M | [4] | SCREW-BUTTON HEAD(M10X1.5X25-MM) | |
| 7. | 5P-4116 | [1] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 8. | 7X-7729 | [4] | WASHER(11X25X3-MM THK) | |
| 9. | 259-1127 | [1] | NUT-CLIP | |
| 10. | 8T-4137M | [4] | BOLT(M10X1.5X20-MM) | |
| 11. | 8T-4189M | [1] | BOLT(M8X1.25X20-MM) | |
| 12. | 8T-4222 | [3] | WASHER-PLATED(11X32X2.5-MM THK) | |
| | D | | ORDER BY THE METER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
