凯斯零件查询(RBX563) - CASE IH ROUND BALER (9/05-12/06) (12.02) - STEP, FIXED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
905 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87016976
|
[1] |
TONGUE
|
PA
|
| 1. |
87016978
|
[1] |
HITCH ASSY
|
PA
Superseded by part number: 87016976
|
| 2. |
87034378
|
[1] |
STEP
|
PA
|
| 2. |
87041522
|
[1] |
STEP
|
PA
|
| 3. |
263636
|
[1] |
ANTI-SKID STRIP
|
NH
|
| 4. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 5. |
614-12030
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 6. |
825-1412
|
[4] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
