纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (6.782[02]) - PLATES AND DECALS DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
170 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76593625 | [1] | DECAL | MACOil Lube Chart |
| 2. | 76593626 | [1] | DECAL | MACBeware High Temperature |
| 3. | 79100878 | [1] | DECAL | LECWarning - Protective Structure Modification |
| 4. | 79100904 | [1] | DECAL | LECParking Brake |
| 5. | 76593631 | [1] | DECAL | MACWarning - Operation |
| 6. | 79089986 | [1] | DECAL | LECEngine Speed |
| 7. | 76025975 | [1] | DECAL | LECDECAL, Danger - Read the Manual |
| 8. | 76038582 | [1] | DECAL | MACWarning - Engine Starting Procedure |
| 9. | 76035021 | [1] | DECAL | MACWarning - Hot Area |
| 10. | 76593633 | [1] | DECAL | MACWarning - Stop Engine |
| 11. | 79100899 | [2] | DECAL | MACWarning - Rotating Blades and Belts |
| 12. | 76598870 | [2] | DECAL | MACDECAL, Danger - Keep Clear |
| 13. | 71433121 | [2] | DANGER DECAL | TOR |
| 14. | 79100900 | [2] | DECAL | LECDanger - Track Release Spring |
| 15. | 79100902 | [2] | DECAL | LECDanger - Fluid Under Pressure (Relief Valve) |
| 16. | 76035836 | [1] | DECAL | LECLifting points |
| 17. | 76593554 | [3] | DECAL | MACLock & Unlock Positions |
| 18. | 76593634 | [4] | DECAL | MACHoisting Direction |
| 19. | 76593558 | [1] | DECAL | MACBlade Tilt & Angle |
| 20. | 76593559 | [1] | DECAL | MACTrack Direction & Turning |
| 21. | 79100897 | [1] | DECAL | LECWarning - Always Turn the Master Switch Off |
| 22. | 76593635 | [2] | DECAL | MACCaution |
| 23. | 79100863 | [1] | DECAL | MACDanger - Fluid Under Pressure (Cap) |
| 24. | 76593636 | [1] | DECAL | MACCaution - Stop Engine Before Changing Filters |
| 25. | 79100898 | [1] | DECAL | MACDanger - Flammable Vapors |
| 26. | 79073482 | [1] | DECAL | MACDanger - Explosive Gases, Poison, Severe Burns |
| 27. | 76593637 | [2] | DECAL | MACCaution - Stop Engine Before Removing the Tank's Cap |
| 28. | 76593638 | [1] | DECAL | MACDiesel |
| 31. | 79099413 | [1] | DECAL | LECOn - Off |
| 32. | 76593561 | [1] | DECAL | MACSeat Belt |
| 33. | 71433086 | [1] | DECAL | LECCaution - Service Manual |
| 34. | 76606042 | [1] | DECAL | MACDECAL |
