纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (3.445[02B]) - ANGLE CYLINDERS DC70 - STD S/N 13041068 & UP, LGP S/N 13045016 & UP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
333 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76607270 | [2] | HYDRAULIC CYLINDER | MACCYLINDER ASSY. |
| 2. | 76591112 | [1] | LUBE NIPPLE | MACGREASE FITTING |
| 3. | 76609692 | [1] | BARREL | MACCYL. TUBE |
| 4. | 76591124 | [2] | ARTICULATION | MACBEARING Superseded by part number: 79037239 |
| 5. | 76591222 | [1] | SCREW | MAC |
| 6. | 76598709 | [1] | PISTON | MAC |
| 11. | 76598710 | [1] | BUSHING | MACGUIDE |
| 16. | 76598721 | [1] | ROD | MACCYL. ROD |
| 17. | 76598712 | [1] | KIT | MACSEAL KIT |
| 18. | 76591125 | [4] | LOCKING RING | MACSNAP RING Superseded by part number: 11061376 |
| 19. | 76598253 | [1] | LUBE NIPPLE | MACGREASE FITTING Superseded by part number: 13408411 |
| 20. | 76591034 | [1] | GASKET | MAC |
| 21. | 76591033 | [1] | PLUG | MAC |
