纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (9.240[01A]) - SALT CHAIN - SHOES (L=558MM) LGP DC70 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
626 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598656 | [2] | SUPPORT | MACCarrier Roller |
| 2. | 76590728 | [12] | WASHER | MAC Superseded by part number: 895-11012 |
| 3. | 76590744 | [4] | NUT | MAC Superseded by part number: 12577521 |
| 5. | 76590781 | [8] | SCREW | MAC Superseded by part number: 615-12035 |
| 6. | 76590727 | [8] | WASHER | MAC Superseded by part number: 412123 |
| 8. | 76598659 | [4] | SCREW | CMI Superseded by part number: 86508581 |
| 9. | 76598660 | [4] | SCREW | MAC |
| 10. | 76598661 | [168] | SCREW | MACScrew, Pad Superseded by part number: 5117440 |
| 11. | 76598662 | [2] | TRACK LINK | MACMaster; One Side Of Link Only; Use With 76598663 |
| 12. | 76598663 | [2] | TRACK LINK | MACMaster; One Side Of Link Only; Use With 76598662 |
| 13. | 76598664 | [168] | NUT | MACNut, Pad Superseded by part number: 5117441 |
| 14. | 76598665 | [2] | KIT | MAC Superseded by part number: 75128930, 76598729, 76598728, 75128929, 75128928 |
| 15. | 76598666 | [48] | SCREW | MAC Superseded by part number: 15215834 |
| 16. | 10517074 | [48] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | TTF Superseded by part number: 412123 |
| 20. | 76598272 | [32] | LOCK WASHER | MAC |
| 21. | 76605592 | [20] | SCREW | MACScrew Superseded by part number: 11119134 |
| 24. | 76598683 | [32] | SCREW | MAC |
| 25. | 76598684 | [1] | CHAIN | MAC |
| 26. | 76598781 | [2] | TRACK ASSY | MACwith Pad Superseded by part number: 76598664, 76598684, 76598783, 76598660, 76598661 |
| 28. | 76598783 | [43] | TRACK SHOE | MAC |
| 29. | 76605593 | [20] | LOCK WASHER | MACWasher Superseded by part number: 10517274 |
| 32. | 76598728 | [43] | PLUG | MACPin |
| 33. | 76598729 | [43] | SET OF RINGS | MACGRP |
