凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (2-08) - GEARBOX ASSEMBLY, 700717910 GEARBOX ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
611 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700717910
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY COMPLETE Superseded by part number: 700725114
|
| 1. |
700710827
|
[2] |
SEAL
|
IH
|
| 2. |
700710828
|
[1] |
OIL SEAL
|
CAS
RING - retaining
|
| 3. |
20879D
|
[3] |
ROLLER BEARING,1.375" ID x 2.77" OD x 0.7813"
|
IH
BEARING - cone, tapered Superseded by part number: 115970
|
| 4. |
700710824
|
[1] |
CASTING
|
CAS
(Thru Holes) Superseded by part number: 700725113, 700725112, 700725334
|
| 5. |
217-433
|
[1] |
PLUG,Hex Soc, 1/4" - 18 NPTF
|
CAS
Superseded by part number: 9617020
|
| 6. |
217-439
|
[1] |
PLUG,Hex Soc, 1/2" - 14 NPTF
|
CAS
1/2 NPT SOLID PLUG Superseded by part number: 86642423
|
| 7. |
61-636
|
[9] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 X 2-1/4 HSHCS Superseded by part number: 61-33836
|
| 8. |
710350
|
[3] |
BRACKET,69.037 mm OD x 15.875 mm
|
CAS
- bearing Superseded by part number: ST991
|
| 9. |
700718137
|
[1] |
GEAR SHAFT
|
CAS
CROSS SHAFT AND GEAR ASSEMBLY Superseded by part number: 700725114
|
| 10. |
700710819
|
[1] |
DIPSTICK
|
CAS
|
| 11. |
700710818
|
[1] |
VALVE
|
CAS
BREATHER
|
| 12. |
444030
|
[1] |
REDUCER,1/2"-14 NPTF x 1/8"-27 Fem NPTF
|
IH
1/2 - 1/8 NPT reducer bushing
|
| 13. |
700710825
|
[1] |
CASTING
|
CAS
(Tapped Holes) Superseded by part number: 700725113, 700725112, 700725334
|
| 14. |
700718136
|
[1] |
GEAR SHAFT
|
CAS
PINION SHAFT AND GEAR ASSEMBLY Superseded by part number: 700725114
|
| 15. |
560953R91
|
[1] |
BEARING ASSY,1.375" ID x 2.875" OD x 0.9688"
|
IH
BEARING - cone, tapered Superseded by part number: 86516471
|
| 16. |
165964R1
|
[1] |
BEARING CUP
|
IH
CUP - bearing Superseded by part number: 86516462
|
