凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (2-18) - CLUTCH MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
852459
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 2. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 3. |
700150200
|
[1] |
COLLAR
|
HFI
|
| 4. |
485-13816
|
[2] |
SET SCREW,Sq Hd, 3/8"-16 x 1"
|
CAS
3/8-16 X 1 CPSQHSS NP Superseded by part number: 84983
|
| 5. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 6. |
700132632
|
[1] |
HUB
|
HFI
ASSEMBLY (Includes items 1 and 7) Superseded by part number: 700132677
|
| 7. |
700712511
|
[2] |
DOWEL
|
CAS
5/8 X 3-1/2 DOWEL PIN
|
| 8. |
8044505
|
[1] |
SEAL
|
CAS
Superseded by part number: 272545
|
| 9. |
700718982
|
[4] |
WASHER
|
CAS
1-1/2 X 14 GAUGE NRMB, hardened P
|
