| 1. |
121-226
|
[6] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 2. |
232-5316
|
[16] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 3. |
700150880
|
[1] |
SUPPORT
|
HFI
|
| 4. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
|
| 5. |
413-672
|
[3] |
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
|
CAS
3/8-16 X 4-1/2 C Superseded by part number: 86505980
|
| 6. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 7. |
700116072
|
[8] |
SHIM
|
CAS
|
| 8. |
700116071
|
[3] |
SPACER
|
HFI
|
| 9. |
413-652
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
|
CAS
Superseded by part number: 9637240
|
| 10. |
700116069
|
[1] |
SPACER
|
HFI
|
| 11. |
700116065
|
[4] |
SPACER
|
HFI
|
| 12. |
700127887
|
[4] |
ARM
|
HFI
- clutch
|
| 13. |
700151476
|
[1] |
SUPPORT
|
HFI
- sensor
|
| 14. |
700126815
|
[4] |
ROLLER
|
CAS
ASSEMBLY (Includes items 15 and 16)
|
| 15. |
D38346
|
[4] |
BALL BEARING,10 mm ID x 30 mm OD x 9 mm
|
CAS
BEARING Superseded by part number: 9847562
|
| 16. |
100-21118
|
[4] |
SNAP RING,1.188", Int, #118
|
CAS
Ring, Snap, 1.188", Int, #118 Superseded by part number: 129738
|
| 17. |
700116070
|
[4] |
SPACER
|
CAS
|
| 18. |
113-252
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5
|
CAS
Superseded by part number: 86505979
|
| 19. |
495-81205
|
[4] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 20. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 21. |
51292
|
[1] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
