现代零件查询R140LC-7A BREAKER CRUSHER ATTACH PIPINGEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
491 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
ROTATING PIPING KIT
|
|
| -2. |
31N4-96220
|
[1] |
ROTATING PIPING-ATT
|
|
| 1. |
008000-000001
|
[1] |
MULTI MAIN BLOCK ASSY
|
|
| 2. |
012050-00120
|
[1] |
BRACKET
|
|
| 3. |
001321-12073
|
[2] |
PIPE-ARM
|
|
| 3. |
001321-12035
|
[2] |
PIPE-ARM
|
|
| 3. |
001321-12049
|
[2] |
PIPR-ARM
|
|
| 3. |
001321-12125
|
[2] |
PIPE-ARM
|
|
| 4. |
P913-086082
|
[2] |
HOSE-HYD
|
|
| 5. |
P933-086034
|
[2] |
HOSE-HYD
|
|
| 5. |
P933-086028
|
[2] |
HOSE-HYD
|
|
| 6. |
X710-100104
|
[2] |
CAP-DUST
|
|
| 7. |
31N1-97010
|
[2] |
STOP VALVE
|
|
| 8. |
X500-110003
|
[4] |
CONNECTOR-ORFS
|
|
| 9. |
X530-110003
|
[2] |
ELBOW-45,ORFS
|
|
| 10. |
31EG-91340
|
[4] |
CLAMP-STOP VLV
|
|
| 11. |
61N1-21500
|
[2] |
BRACKET-STOP VLV
|
|
| 12. |
31EG-91370
|
[2] |
CLAMP-PIPE
|
|
| 12. |
31EG-91370
|
[4] |
CLAMP-PIPE
|
|
| 13. |
61E6-10450
|
[2] |
BRACKET-PIPE
|
|
| 13. |
61E6-10450
|
[4] |
BRACKET-PIPE
|
|
| 14. |
010007-12000
|
[2] |
I-CLAMP
|
|
| 15. |
31EK-11130
|
[3] |
COUPLING-SCREW
|
|
| 16. |
012060-000001
|
[1] |
TERMINAL ASSY
|
|
| 17. |
012060-000002
|
[1] |
TERMINAL ASSY
|
|
| 18. |
S631-011004
|
[3] |
O-RING
|
|
| 19. |
S631-018004
|
[8] |
O-RING
|
|
| 20. |
S621-014001
|
[8] |
O-RING
|
|
| 21. |
S017-100256
|
[4] |
BOLT-HEX
|
|
| 22. |
S017-100456
|
[4] |
BOLT-HEX
|
|
| 22. |
S017-100456
|
[8] |
BOLT-HEX
|
|
| 23. |
S017-100556
|
[4] |
BOLT-HEX
|
|
| 24. |
S017-160256
|
[4] |
BOLT-HEX
|
|
| 25. |
S017-160706
|
[2] |
BOLT-HEX
|
|
| 26. |
S017-160756
|
[4] |
BOLT-HEX
|
|
| 27. |
S411-100006
|
[8] |
WASHER-SPRING
|
|
| 27. |
S411-100006
|
[16] |
WASHER-SPRING
|
|
| 28. |
S411-160006
|
[10] |
WASHER-SPRING
|
|
