纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (04-04) - ALTERNATOR MOUNTING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
884 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 2853215 | [1] | BRACKET | TORMounting Strap Superseded by part number: 504076666 |
| 3. | 18138424 | [1] | SCREW,Hex Flg, M8 x 1.25 x 20mm | LEC |
| 4. | 832-10410 | [1] | NUT,M10 x 1.5, Cl 8 | CASUsed with 827-10130, Bolt and 87452257, Spacer Superseded by part number: 190003888452 |
| 4. | 4895166 | [1] | FLANGE NUT,M10, 1.50mm Pitch, Cl 10 | BAS |
| 5. | 827-10130 | [1] | BOLT,Hex, M10 x 1.5 x 130mm, Cl 10.9 | CASUsed with 832-10410, Nut and 87452257, Spacer Superseded by part number: 84577051 |
| 5. | 4895538 | [1] | FLANGE BOLT,Hex, M10 x 1.5 x 120mm | TOR Superseded by part number: 16599025 |
| 6. | 87452257 | [1] | SPACER | BURNo Longer Required, Used with 832-10410, Nut and 827-10130, Bolt |
| 7. | 855-8020 | [1] | BOLT,Hvy Hex, M8 x 20mm, Cl 10.9 | CAS Superseded by part number: 87344207 |
| 8. | 896-11010 | [2] | WASHER,11mm ID x 21mm OD x 2.5mm Thk | CAS Superseded by part number: 86625252 |
