凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (6-12) - BELT TENSIONING ROLLER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
281 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
432-1228
|
[1] |
COTTER PIN,3/16" x 1 3/4"
|
CAS
3/16" x 1 3/4" Superseded by part number: 87399
|
| 2. |
705574
|
[1] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
| 3. |
700135516
|
[1] |
PIN
|
HFI
|
| 4. |
413-880
|
[1] |
BOLT,Hex, 1/2" - 13 x 5", Gr 5
|
CAS
1/2-13 X 5 C Superseded by part number: 87997
|
| 5. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 6. |
700716064
|
[1] |
BUSHING
|
CAS
- bronze
|
| 7. |
700135518
|
[1] |
TUBE,0.562" ID, 25.4 mm OD, 102 mm Length
|
HFI
|
| 8. |
700135520
|
[1] |
GUIDE
|
HFI
WA - belt
|
| 9. |
121-226
|
[5] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 10. |
232-5316
|
[5] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 11. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 12. |
700135701
|
[1] |
ARM
|
HFI
WA - upper
|
| 13. |
700107934
|
[2] |
ROLL
|
IH
ER ASSEMBLY (Includes item 14)
|
| 14. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 15. |
700100927
|
[4] |
HUB
|
L
|
| 16. |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 X 1-3/4 HSFCHCS
|
| 17. |
700135537
|
[1] |
SUPPORT
|
HFI
CHANNEL WA - upper, outer (Includes item 6)
|
