现代零件查询R15-7 POWER UNIT 1EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
553 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-02788
|
[1] |
ENGINE ASSY
|
|
| 1. |
XJDH-04294
|
[1] |
ENGINE ASSY
|
|
| 2. |
XJDH-01156
|
[1] |
BRACKET-ENGINE (A)
|
|
| 3. |
XJDH-01157
|
[1] |
BRACKET-ENGINE (B)
|
|
| 4. |
XJDH-02872
|
[8] |
BOLT
|
|
| 5. |
XJDH-00278
|
[8] |
WASHER
|
|
| 6. |
XJDH-03207
|
[1] |
COUPLING
|
|
| 7. |
XJDH-00130
|
[3] |
BOLT-SOCKET HEAD
|
|
| 8. |
XJDH-01159
|
[1] |
PUMP FLANGE
|
|
| 9. |
XJDH-02882
|
[8] |
BOLT
|
|
| 10. |
XJDH-00278
|
[8] |
WASHER
|
|
| 11. |
XJDH-02883
|
[2] |
BOLT
|
|
| 12. |
XJDH-01055
|
[2] |
WASHER
|
|
| 13. |
XJDH-03208
|
[8] |
RUBBER-ABSORBER
|
|
| 14. |
XJDH-03065
|
[4] |
BOLT
|
|
| 15. |
XJDH-00266
|
[4] |
WASHER
|
|
| 16. |
XJDH-01070
|
[1] |
CORD-GROUND
|
|
| 17. |
XJDH-00144
|
[1] |
BOLT
|
|
| 18. |
XJDH-00278
|
[1] |
WASHER
|
|
| 19. |
XJDH-02905
|
[1] |
WASHER-TOOTHED
|
|
| 20. |
XJDH-00032
|
[1] |
BOLT
|
|
| 21. |
XJDH-00276
|
[1] |
WASHER
|
|
| 22. |
XJDH-00270
|
[1] |
WASHER-TOOTHED
|
|
| 23. |
XJDH-01268
|
[1] |
BRACKET-ACCELERATOR
|
|
| 24. |
XJDH-00032
|
[2] |
BOLT
|
|
| 25. |
XJDH-00276
|
[2] |
WASHER
|
|
| 26. |
XJDH-02874
|
[2] |
BOLT
|
|
| 27. |
XJDH-00184
|
[2] |
NUT
|
|
| 28. |
XJDH-01344
|
[1] |
LEVER-ACCELERATOR
|
|
| 29. |
XJDH-01048
|
[1] |
GRIP
|
|
| 30. |
XJDH-02908
|
[4] |
WASHER-CONICAL
|
|
| 31. |
XJDH-00266
|
[4] |
WASHER
|
|
| 32. |
XJDH-02897
|
[2] |
NUT
|
|
| 33. |
XJDH-00838
|
[1] |
WIRE-ACCELERATOR
|
|
| 34. |
XJDH-00289
|
[2] |
PIN
|
|
| 35. |
XJDH-00255
|
[2] |
WASHER
|
|
| 36. |
XJDH-02910
|
[2] |
PIN-SPLIT
|
|
| 37. |
XJDH-01158
|
[1] |
BRACKET
|
|
| 38. |
XJDH-02896
|
[8] |
NUT
|
|
