现代零件查询R15-7 ENGINE COVEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-03049
|
[1] |
COVER-ENGINE(A)
|
|
| 2. |
XJDH-02884
|
[6] |
BOLT
|
|
| 3. |
XJDH-00278
|
[6] |
WASHER
|
|
| 4. |
XJDH-02993
|
[1] |
STRIP-WEATHER
|
|
| 5. |
XJDH-02992
|
[2] |
STRIP-WEATHER
|
|
| 6. |
XJDH-01271
|
[1] |
PLATE
|
|
| 7. |
XJDH-00032
|
[4] |
BOLT
|
|
| 8. |
XJDH-00276
|
[4] |
WASHER
|
|
| 9. |
XJDH-01283
|
[1] |
COVER-ENGINE (B)
|
|
| 10. |
XJDH-00032
|
[5] |
BOLT
|
|
| 11. |
XJDH-00276
|
[5] |
WASHER
|
|
| 12. |
XJDH-02993
|
[1] |
STRIP-WEATHER
|
|
| 13. |
XJDH-01284
|
[1] |
COVER-ENGINE(C)
|
|
| 14. |
XJDH-00001
|
[1] |
LATCH
|
|
| 15. |
XJDH-00215
|
[2] |
SCREW-PANHEAD
|
|
| 16. |
XJDH-00253
|
[2] |
WASHER
|
|
| 17. |
XJDH-00032
|
[3] |
BOLT
|
|
| 18. |
XJDH-00276
|
[3] |
WASHER
|
|
| 19. |
XJDH-03050
|
[1] |
COVER-ENGINE(D)
|
|
| 20. |
XJDH-00032
|
[5] |
BOLT
|
|
| 21. |
XJDH-00276
|
[5] |
WASHER
|
|
| 22. |
XJDH-01273
|
[1] |
PLATE
|
|
| 23. |
XJDH-01413
|
[1] |
COVER-ENGINE ASSY (B)
|
|
| 24. |
XJDH-01007
|
[1] |
CYLINDER KEY ASSY
|
|
| 25. |
XJDH-01789
|
[1] |
LOCK ASSY
|
|
| 26. |
XJDH-00019
|
[2] |
BOLT
|
|
| 27. |
XJDH-00274
|
[2] |
WASHER
|
|
| 28. |
XJDH-00722
|
[1] |
WEATHER STRIP
|
|
| 29. |
XJDH-00718
|
[1] |
WEATHER STRIP
|
|
| 30. |
XJDH-00856
|
[2] |
HINGE
|
|
| 31. |
XJDH-00032
|
[8] |
BOLT
|
|
| 32. |
XJDH-00276
|
[8] |
WASHER
|
|
| 33. |
XJDH-01180
|
[1] |
GUIDE-SLIDE
|
|
| 34. |
XJDH-00278
|
[2] |
WASHER
|
|
| 35. |
XJDH-00296
|
[2] |
PIN-SPLIT
|
|
| 36. |
XJDH-01412
|
[1] |
BRACKET ASSY
|
|
| 37. |
XJDH-00047
|
[2] |
BOLT
|
|
| 38. |
XJDH-00278
|
[2] |
WASHER
|
|
| 39. |
XJDH-01788
|
[1] |
STRIKER
|
|
| 40. |
XJDH-00037
|
[2] |
BOLT
|
|
| 41. |
XJDH-00262
|
[2] |
WASHER
|
|
| 42. |
XJDH-01406
|
[AR] |
SHIM(2.3T)
|
|
| 43. |
XJDH-01407
|
[AR] |
SHIM(1.2T)
|
|
| 44. |
XJDH-01266
|
[1] |
URETHAN FOAM ASSY
|
|
| 45. |
XJDH-01274
|
[1] |
FOAM-URETHAN
|
|
| 46. |
XJDH-01008
|
[1] |
HANDLE
|
|
| 47. |
XJDH-02987
|
[1] |
GROMMET
|
|
| 48. |
XJDH-02991
|
[1] |
STRIP-WEATHER
|
|
| 49. |
XJDH-01275
|
[1] |
FOAM-URETHAN
|
|
| 50. |
XJDH-01280
|
[1] |
FOAM-URETHAN
|
|
| 51. |
XJDH-01811
|
[1] |
BRACKET
|
|
| 52. |
XJDH-01810
|
[1] |
PLATE
|
|
