纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (09-35) - CAB - WASHER, WINDSHIELD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
521 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 389423A3 | [1] | WINDSHIELD WASH RESERVOIR | BURTank Assembly; Incl. Ref 1 - 4; Not Available As An Assembly, Order Components Superseded by part number: 386721A4, 307130A1, 196830A1, E47238 |
| 1. | 386721A4 | [1] | RESERVOIR | CASWindshield Washer Tank |
| 2. | 196830A1 | [2] | GROMMET | CAS |
| 3. | E47238 | [2] | PUMP,12V | CASMotor |
| 4. | 307130A1 | [1] | COVER | CAS |
| 5. | 905-8020 | [2] | BOLT,Hex Flg, M8 x 20mm | CASM8 x 20 Superseded by part number: 86511479 |
| 6. | 832-4748 | [2] | FLANGE NUT,M8 x 1.25, Flg, Cl 8 | CAS Superseded by part number: 86050303 |
| 7. | 87409799 | [1] | HOSE | BUR240 mm (9-1/2 in); Cut From 397154A1; Out To Tee Fitting |
| 8. | 87427778 | [1] | FITTING | CASTee; 3/16 in |
| 9. | 87427794 | [2] | HOSE | BUR700 mm (27-1/2 in); Cut From 397154A1 |
| 10. | 87427795 | [1] | HOSE | BUR3000 mm (118 in); Cut From 397154A1 |
| . . | 397154A1 | [1] | HOSE WASHER | CASBulk, 100 ft |
| 11. | L18331 | [1] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 13. | 305578A1 | [2] | CLAMP,7.65mm - 8.76mm | CAS |
| 14. | 492-11038 | [2] | LOCK WASHER,3/8" | CAS Superseded by part number: 72187249, 80680 |
| 15. | 425-106 | [2] | NUT,3/8"-16, Cl 5 | CAS Superseded by part number: 9628503 |
| 16. | 284154A1 | [2] | NOZZLE,3/8" - 16 | CASIncludes A Steel and Rubber Washer, Which Are Not Serviced Separately |
