现代零件查询R16-7 BOOM CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-02811
|
[1] |
BOOM CYLINDER ASSY
|
|
| 2. |
XJDH-03111
|
[1] |
CYLINDER TUBE ASSY
|
|
| 3. |
XJDH-03112
|
[1] |
PISTON ROD ASSY
|
|
| 4. |
XJDH-03113
|
[1] |
CYLINDER HEAD
|
|
| 5. |
XJDH-03114
|
[1] |
BUSHING
|
|
| 6. |
XJDH-03115
|
[1] |
U-RING
|
|
| 7. |
XJDH-03116
|
[1] |
RING-BACK UP
|
|
| 8. |
XJDH-03117
|
[1] |
RING-WIPER
|
|
| 9. |
XJDH-03118
|
[1] |
O-RING
|
|
| 10. |
XJDH-03119
|
[2] |
RING-BACK UP
|
|
| 11. |
XJDH-03120
|
[1] |
O-RING
|
|
| 12. |
XJDH-03121
|
[1] |
O-RING
|
|
| 13. |
XJDH-03122
|
[1] |
RING-CUSHION
|
|
| 14. |
XJDH-03123
|
[1] |
SPACER
|
|
| 15. |
XJDH-03124
|
[1] |
STOPPER
|
|
| 16. |
XJDH-03125
|
[1] |
PISTON
|
|
| 17. |
XJDH-03126
|
[2] |
RING-SLIDE
|
|
| 18. |
XJDH-03127
|
[1] |
RING ASSY-SEAL
|
|
| 19. |
XJDH-03128
|
[1] |
BALL-STEEL
|
|
| 20. |
XJDH-03129
|
[1] |
SCREW-SET
|
|
| 21. |
XJDH-03130
|
[1] |
CUSHION BEARING
|
|
| 22. |
XJDH-03131
|
[1] |
BUSHING-PIN
|
|
| 23. |
XJDH-03132
|
[4] |
SEAL-DUST
|
|
| 24. |
XJDH-03133
|
[1] |
CYLINDER HEAD ASSY
|
|
| 25. |
XJDH-03134
|
[1] |
PISTON ASSY
|
|
| 26. |
XJDH-03135
|
[1] |
ROD PACKING ASSY
|
|
| 27. |
XJDH-03136
|
[1] |
PISTON PACKING ASSY
|
|
| 28. |
XJDH-02812
|
[1] |
PACKING ASSY
|
|
| 29. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
| 30. |
XJDH-00377
|
[1] |
NIPPLE-GREASE 90
|
|
