纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (09-55) - DECALS - LATIN AMERICAN SPANISH New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
226 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87422188 | [1] | DECAL | BURThrottle |
| 3. | 379422A1 | [1] | DECAL | CASMaster Disconnect Switch |
| 4. | 87412595 | [1] | DECAL | BURIgnition Switch |
| 5. | 87439445 | [1] | DECAL | BURFuse/Relays, In Cab/Canopy Assembly |
| 6. | 87441773 | [1] | DECAL | BURFuse/Relays |
| 9. | 87355190 | [1] | DECAL | BURCanopy/Cab Tilting Procedure; Replaces 87421181 |
| 10. | 87422184 | [1] | DECAL | BURForward/Neutral/Reverse |
| 11. | 87421179 | [1] | DECAL | BURReverse Controller; Replaces 87422186 |
| 12. | 87453402 | [1] | DECAL | BURDiagnostics |
| 13. | 87454610 | [1] | DECAL | CASWarning, Do Not Modify or Repair ROPS or FOPS In Any Manner |
| 14. | 87453592 | [1] | DECAL | BURWarning, Engine Decelerator Pedal |
| 15. | 449842A1 | [2] | REFLECTOR | BURReflector, Rectangular; 50.8 (2 in) x 160 mm (6-5/16 in) |
