现代零件查询R16-7 EXTEND CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
411 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-04163
|
[1] |
EXTEND CYLINDER ASSY
|
|
| 2. |
XJDH-04164
|
[1] |
CYL TUBE ASSY
|
|
| 3. |
XJDH-04165
|
[1] |
PISTON ROD ASSY
|
|
| 4. |
XJDH-04166
|
[1] |
CYLINDER HEAD
|
|
| 5. |
XJDH-03150
|
[1] |
BUSHING
|
|
| 6. |
XJDH-03151
|
[1] |
U-RING
|
|
| 7. |
XJDH-04167
|
[1] |
WIPER RING
|
|
| 8. |
XJDH-04168
|
[1] |
O-RING
|
|
| 9. |
XJDH-04169
|
[1] |
RING-BACKUP
|
|
| 10. |
XJDH-04170
|
[1] |
O-RING
|
|
| 11. |
XJDH-04171
|
[1] |
PISTON
|
|
| 12. |
XJDH-04172
|
[2] |
RING-SLIDE
|
|
| 13. |
XJDH-04173
|
[1] |
SEAL RING ASSY
|
|
| 14. |
XJDH-03128
|
[1] |
BALL-STEEL
|
|
| 15. |
XJDH-03154
|
[1] |
SCREW-SET
|
|
| 16. |
XJDH-04174
|
[1] |
CYL HEAD ADDY
|
|
| 17. |
XJDH-04175
|
[1] |
PISTON ASSY
|
|
| 18. |
XJDH-04176
|
[1] |
ROD PACKING ASSY
|
|
| 19. |
XJDH-04177
|
[1] |
PISTON PACKING ASSY
|
|
| 20. |
XJDH-04178
|
[1] |
PACKING ASSY
|
|
