纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (05-02) - FRAME, TRACK - COVERS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
204 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 86987763 | [2] | COVER ASSY | BURIdler; Left-Hand |
| 2. | 86987764 | [2] | COVER ASSY | BURIdler; Right-Hand |
| 3. | 413-820 | [4] | BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5 | CAS Superseded by part number: 87670, 72187215 |
| 3A. | 413-812 | [4] | BOLT,Hex, 1/2" - 13 x 3/4", Gr 5 | CAS1/2 x 3/4; Not Illustrated Superseded by part number: 9627879 |
| 4. | 496-21053 | [8] | WASHER,17/32" x 1 1/16" x .134" | CAS Superseded by part number: 86624188 |
| 5. | 129-857 | [4] | SQUARE NUT,Sq, 1/2"-13 | CAS |
| 6. | 336371A1 | [4] | PIN | CASNut Retainer |
| 7. | 86987765 | [2] | COVER ASSY | BURIdler; Top Superseded by part number: 87566815 |
| 8. | 86987760 | [1] | COVER ASSY | BURRight-Hand; Inner; Forward Superseded by part number: 87591659 |
| 9. | 86987755 | [1] | COVER ASSY | BURLeft-Hand; Inner; Forward Superseded by part number: 87591653 |
| 10. | 86987759 | [1] | COVER ASSY | BURRight-Hand; Inner; Mid Forward Superseded by part number: 87591658 |
| 11. | 86987753 | [1] | COVER ASSY | BURLeft-Hand; Inner; Mid Forward Superseded by part number: 87591652 |
| 12. | 86987762 | [1] | COVER ASSY | BURRight-Hand; Outer; Forward Superseded by part number: 87591661 |
| 13. | 86987754 | [1] | COVER ASSY | BURLeft-Hand; Outer; Forward Superseded by part number: 87591655 |
| 14. | 86987758 | [1] | COVER ASSY | BURRight-Hand; Inner; Mid Rear Superseded by part number: 87591657 |
| 15. | 86987752 | [1] | COVER ASSY | BURLeft-Hand; Inner; Mid Rear Superseded by part number: 87591651 |
| 16. | 86987757 | [1] | COVER ASSY | BURRight-Hand; Inner; Rear Superseded by part number: 87591656 |
| 17. | 86987756 | [1] | COVER ASSY | BURLeft-Hand; Inner; Rear Superseded by part number: 87591650 |
| 18. | 86987761 | [1] | COVER ASSY | BURRight-Hand; Outer; Rear Superseded by part number: 87591660 |
| 19. | 86987751 | [1] | COVER ASSY | BURLeft-Hand; Outer; Rear Superseded by part number: 87591654 |
