凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (4-16) - ELECTRICAL ASSEMBLY, KICKER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
315 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700718506
|
[1] |
CLIP
|
CAS
- plastic, barbed
|
| 2. |
700716454
|
[1] |
PLUG
|
CAS
JUMPER
|
| 3. |
700135980
|
[1] |
SUPPORT
|
HFI
WA
|
| 4. |
496-81010
|
[2] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 5. |
700707978
|
[1] |
SPRING
|
IH
- compression
|
| 6. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 7. |
700150917
|
[1] |
SHIELD
|
HFI
WA
|
| 8. |
700716200
|
[1] |
BOLT
|
CAS
HFS 3/8-16 X 3
|
| 9. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 10. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 11. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
|
| 12. |
700710188
|
[7] |
SCREW
|
CAS
#6-32 X 3/4 CRPHMS (Stainless)
|
| 13. |
700710187
|
[8] |
WASHER
|
CAS
#6 WPW (Stainless)
|
| 14. |
700710189
|
[7] |
LOCK NUT
|
CAS
#6-32 LHSN (Stainless)
|
| 15. |
700710199
|
[6] |
GROMMET
|
CAS
|
| 16. |
700709996
|
[1] |
SWITCH
|
IH
ACTUATOR - switch
|
| 17. |
700710208
|
[2] |
ROTARY SWITCH
|
L
SWITCH (N.O.)
|
| 18. |
7883275
|
[1] |
SCREW,Hex Washer, 1/4" - 20 x 3/4"
|
CAS
1/4-20 X 3/4 HWHMS
|
| 19. |
1703354
|
[1] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 20. |
515-25127
|
[1] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 21. |
515-2179
|
[2] |
CLAMP,5/16", Insul, 1/4" Bolt
|
CAS
Line 5/16", Insul, 1/4" Bolt Superseded by part number: 237910
|
| 22. |
121-3
|
[2] |
SERRATED BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
|
| 23. |
700150915
|
[1] |
SHIELD
|
HFI
|
| 24. |
702400102
|
[1] |
CONDUIT
|
CAS
- split
|
| 25. |
700718012
|
[1] |
SWITCH
|
CAS
- assembly (NC)
|
| 26. |
281-34912
|
[4] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHTCTS
|
| 27. |
700119161
|
[1] |
SWITCH
|
L
- assembly (NO)
|
| 28. |
700150916
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - switch
|
| 29. |
700710211
|
[1] |
ACTUATOR
|
IH
|
| 30. |
700135943
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - actuator
|
