纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (05-08) - TRACK GUARDS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
371 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87353990 | [4] | COVER, REAR, Replaces 86987749 | |
| 2. | 409-91024 | [16] | BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 5 | CAS5/8 x 1-1/2 in Superseded by part number: 86622997 |
| 3. | 496-21066 | [16] | WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk | CAS Superseded by part number: 5122064 |
| 4. | 86987746 | [2] | GUARD ASSY. | BURLeft-Hand Rear; Not Illustrated |
| 5. | 86987745 | [2] | GUARD ASSY. | BURRight-Hand Rear |
| 6. | 413-12144 | [8] | BOLT,Hex, 3/4" - 10 x 9", Gr 5 | CAS3/4 x 9 Superseded by part number: 280441 |
| 7. | 496-11081 | [16] | WASHER,13/16" x 1 1/2" x .134", HDN | CAS Superseded by part number: 394632 |
| 8. | 141188A1 | [8] | SPACER | CAS |
| 9. | 231-41112 | [8] | LOCK NUT,3/4"-10, GB | CAS |
| 10. | 86987750 | [4] | GUARD ASSY. | CASCenter |
| 11. | 86987747 | [2] | GUARD | BURLeft-Hand Front; Not Illustrated |
| 12. | 86987748 | [2] | GUARD | BURRight-Hand Front |
| 13. | 87018373 | [36] | BOLT,Hex, 1/2" - 13 x 1.25", Gr 5, Full Thd | BRR1/2 x 1-1/4 |
| 14. | 496-21053 | [36] | WASHER,17/32" x 1 1/16" x .134" | CAS Superseded by part number: 86624188 |
| 15. | 129-860 | [4] | SQUARE NUT,Sq, 5/8"-11 | CAS |
| 16. | 336371A1 | [4] | PIN | CASNut Retainer |
