凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (8-14) - HYD. CYLINDER ASSY.,TAILGATE, W/ MESH WRAP, 700717928 HYD. CYL. ASSY. COMPLETE, 2" BORE X 20" STROKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
764 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700717928
|
[1] |
CYLINDER
|
CAS
HYDRAULIC CYLINDER ASM. COMPLETE (2 Inch Bore x 20 Inch Stroke)
|
| 2. |
700718149
|
[1] |
GUIDE
|
CAS
- rod
|
| 3. |
700718150
|
[1] |
NUT
|
CAS
SPANNER NUT
|
| 4. |
700718154
|
[1] |
ROD
|
CAS
- piston
|
| 5. |
774315
|
[1] |
NUT
|
CAS
7/8-14 UNF HTLN GR C
|
| 6. |
700710421
|
[1] |
PISTON
|
CAS
|
| 7. |
700718146
|
[1] |
KIT
|
CAS
SEAL AND O-RING REPAIR KIT, Includes items in art marked with asterisk
|
